LyoPuck for RF Loggers

LyoPuck RF

temperature spec

Main description

+ Main feature 1
+ Main feature 2
+ Main feature 3
+ Main feature 4
+ Main feature 5

Order Reference

LyoPuck-RF

Documents

Specifications

Characteristics

LVSC.3.2.0 - January 2022

Sensors

Interchangeable sensors
Most common sensor types: PT-100, Tc's, Humidity, Pressure, CO₂

Channels

64 channels
Cold junction compensation on each channel (applies to Tc's)

Measuring range

-200°C to +1200°C

Accuracy

up to ±0.05°C

Memory capacity

Internal memory: 16 GB
Backup memory: USB storage device compatible

Sampling rate

1 s to 24h for 64 channels

Display

Touch screen, 10.1"

Software

21 CFR Part 11 Compliant

Universal input

4 - 20 mA / 0-10 V

Communication

1 x USB to PC
2 x USB to equipment
1 x LAN to PC (with Power Over Ethernet)
2 x LAN to equipment
1 x 2.4 GHz, 802.11b/g/n

Battery

Internal rechargeable battery
Can run on battery for several hours without interruption

Main power

100V to 240V @ 50/60Hz

Synchronization

Multiple units can be synchronized to run simultaneously

Closed loop calibration

Required when using thermocouples for thermal validation
System uses temperature block and reference probe, controlled with or without software. Reports generated automatically by the software.

Reference probes

USB XpertVal to PC
LAN
2.4 GHz, 802.11b/g/n

Reference probes

Lives XpertRTD, Fluke 1502A, IQRTD

Dry blocks

Compatible with blocks from: Ametek, Fluke, Sika, Isotech

Calibrations

Sensor Calibration: NIST / COFRAC
User: closed loop calibration with or without XpertLog^® Software

Other

Silent operation (no mechanical relays)
Can be used standalone, can be operated from XpertLog^® software, can be operated from mobile devices.

Order reference

XPERTVAL64

Find out more about XpertVal 64
